The System Information page displays.

5. Scroll down to the Fan Status section.

6. To refresh the page, click the Refresh button.

The following table describes the view-only fan status fields. The table can show the
fan status for up to eight stacked switches. The number of fans depends on the switch
model.

Table 5. Fan status information

Description

Field

The unit ID of the switch in which the fan is installed.

Unit ID

The fan number

FAN

The fan description, such as FAN-1, FAN-2, and so on.

Description

The type of fan, which is always fixed.

Type

The speed of the fan.

For more information, see the hardware installation guide, which you can
download by visiting netgear.com/support/download/.

Speed

The duty level of the fan in percentage.

Duty level

The status of the fan:

Operational: The fan is running normally.

Failure: The fan failed.

Not Present: The fan is not present. (The number of fans depends on

the switch model.)

Stop: The fan stopped because the switch temperature is low. The fan

will start if the switch temperature rises.

FAN Status

View the temperature sensor information

You can view the current temperature of different system sensors using the Temperature
Status table.

To view temperature information:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

If you do not know the IP address of the switch, see Log in to the main UI with a web
browser
on page 27 and the subsections.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.
