Your settings are saved.

11. To save the settings to the running configuration, click the Save icon.

The following table describes the view-only fields on the page.

Table 185. Syslog configuration information

Description

Field

The number of messages received by the log process. This includes messages
that are dropped or ignored.

Messages Received

The number of syslog messages relayed.

Messages Relayed

The number of syslog messages ignored.

Messages Ignored

Add a syslog server

To add a syslog server:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

If you do not know the IP address of the switch, see Log in to the main UI with a web
browser
on page 27 and the subsections.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.

The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Select Monitoring > Logs > Server Log.

The Server Log page displays.

6. In the Server Configuration table, configure the following settings:

IP Address Type: Specify the IP address type of the syslog server, which can be
IPv4, IPv6, or DNS.

Host Address: Specify the IP address or host name of the syslog server.

Port: Specify the port on the syslog server. The default port number is 514.

Severity Filter: Use the menu to select the severity of the logs that must be sent
to the syslog server. Logs with the selected severity level and all logs of greater
