address to a destination IP address. This type of ACL provides more granularity
and filtering capabilities than the basic IP ACL.
•
Named IP ACL: Creates an extended IPv4 ACL with a name string that is up to
31 alphanumeric characters in length. The name must start with an alphabetic
character.
2. Create an IPv4 rule (see Configure rules for a basic IP ACL on page 808 or Configure
rules for an extended IPv4 ACL on page 811).
3. Associate the IPv4 ACL with one or more interfaces (see Configure IP ACL interface
bindings on page 829).
You can display or delete IPv4 ACL configurations in the IP ACL Binding table (see
Display or delete IP ACL bindings in the IP ACL binding table on page 831.
Add an IPv4 ACL
You can add an IPv4 ACL, after which you can add a rule for the IPv4 ACL (see Add a
rule for a basic IPv4 ACL on page 808 or Add a rule for an extended IPv4 ACL on page
812).
To add an IPv4 ACL:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see Log in to the main UI with a web
browser on page 27 and the subsections.
The login page displays.
3. Click the Main UI Login button.
The main UI login page displays in a new tab.
4. Enter admin as the user name, enter your local device password, and click the Login
button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The System Information page displays.
5. Select Security > ACL > Advanced > IP ACL.
The IP ACL page displays.
The IP ACL page shows the current size of the ACL table compared to the maximum
size of the ACL table. The current size is equal to the number of configured IPv4
ACLs plus the number of configured MAC ACLs and IPv6 ACLs. The maximum
number of ACLs on the switch is 100.
