To configure a single LAG and its membership:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see Log in to the main UI with a web
browser on page 27 and the subsections.
The login page displays.
3. Click the Main UI Login button.
The main UI login page displays in a new tab.
4. Enter admin as the user name, enter your local device password, and click the Login
button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The System Information page displays.
5. Select Switching > LAG > LAG Membership.
The LAG Membership page displays.
6. From the LAG ID to menu, select the LAG.
7. To change the default name of the LAG, in the LAG Name field, enter the name to
be assigned to the LAG.
By default, the names are ch1, ch2, ch3, and so on. You can enter a name of up to
15 characters.
8. To enter a description for the LAG, in the LAG Description field, enter a description
of up to 64 characters.
9. From the Admin Mode menu, select to enable or disable the LAG.
When the LAG is disabled, no traffic flows and LACPDUs are dropped, but the links
that form the LAG are not released. The default is Enable.
10. From the Link Trap menu, select to enable or disable the transmission of a trap when
the LAG link status changes.
The default is Enable, which allows a trap to be sent.
11. From the STP Mode menu, select to enable or disable the Spanning Tree Protocol
(STP) administrative mode for the LAG.
Enable is the default.
12. From the Static Mode menu, select to enable or disable the LAG as a static LAG.
When the static mode is enabled, the LAG does not transmit or process incoming
LACPDUs. That is, a LAG member port does not transmit LACPDUs, and LACPDUs
that it receives are dropped. The default is Disable.
13. From the Hash Mode menu, select the load-balancing mode for the LAG:
