Table 27. Green Ethernet interface summary information

Description

Field

The interface for which information is displayed.

Interface

Indicates the status of the mode (Enable or Disable).

If the mode is enabled and a port link is down, the underlying physical

layer goes down for a short period and then checks for port link pulses

again so that auto-negotiation remains possible. In this way, the switch

saves power when no link partner is present for the port.

Energy Detect Admin Mode

The operational state (Active or Inactive) of the Energy Detect mode.

Energy Detect Operational Status

Indicates the status of the mode (Enable or Disable).

If this mode is enabled, the port transitions to low power mode during

a link idle condition.

EEE Admin mode

Configure and display the green Ethernet EEE LPI history
for an interface

You can configure and display the green Ethernet EEE low-power idle (LPI) history for
an interface.

To configure and display the green Ethernet EEE LPI history for an interface:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Select System > Management > Green Ethernet > Green Ethernet LPI History.

The Green Ethernet LPI History page displays.

6. From the Interface menu, select the interface.
