The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Select System > ISDP > Advanced > Statistics.

The Statistics page displays.

6. To refresh the page, click the Refresh button.

7. To clear the ISDP statistics, click the Clear button.

The statistics are cleared.

8. To save the settings to the running configuration, click the Save icon.

The following table describes the nonconfigurable fields on the page.

Table 51. ISDP statistics information

Description

Field

The ISDPv2 and ISDPv3 packets received on the switch.

ISDP Packets Received

The ISDPv2 and ISDPv3 packets transmitted on the switch.

ISDP Packets Transmitted

The ISDPv1 packets received on the switch.

ISDPv1 Packets Received

The ISDPv1 packets transmitted on the switch.

ISDPv1 Packets Transmitted

The ISDPv2 packets received on the switch.

ISDPv2 Packets Received

The ISDPv2 packets transmitted on the switch.

ISDPv2 Packets Transmitted

The ISDP packets with bad headers received on the switch.

ISDP Bad Header

The ISDP packets with checksum errors received on the switch.

ISDP Checksum Error

The number of ISDP packets that the switch failed to transmit.

ISDP Transmission Failure

The number of ISDP packets with an invalid format that the switch received.

ISDP Invalid Format

The size of the ISDP table.

ISDP Table Full

The size of the ISDP IP address table.

ISDP IP Address Table Full
