This is known as inter-VLAN routing. On the switch, it is accomplished by creating Layer
3 interfaces (switch virtual interfaces [SVI]).
When a port is enabled for bridging (the default) rather than routing, all normal bridge
processing is performed for an inbound packet, which is then associated with a VLAN.
Its MAC destination address (MAC DA) and VLAN ID are used to search the MAC address
table. If routing is enabled for the VLAN, and the MAC DA of an inbound unicast packet
is that of the internal bridge-router interface, the packet is routed. An inbound multicast
packet is forwarded to all ports in the VLAN, plus the internal bridge-router interface,
if it was received on a routed VLAN.
Because a port can be configured to belong to more than one VLAN, VLAN routing
might be enabled for all of the VLANs on the port, or for a subset. VLAN routing can be
used to allow more than one physical port to reside on the same subnet. It could also
be used when a VLAN spans multiple physical networks, or when additional segmentation
or security is required. A port can be either a VLAN port or a router port, but not both.
However, a VLAN port can be part of a VLAN that is itself a router port.
Complete these steps to configure a switch to perform interVLAN routing for IPv4:
1. Use the IP Configuration page to enable IPv4 routing on the switch.
By default, IPv4 routing is enabled. For more information about this step, see Manage
the global IPv4 routing settings on page 342.
2. Determine the IP addresses that you want to assign to the VLAN interface on the
switch.
For the switch to be able to route between the VLANs, the VLAN interfaces must be
configured with an IP address. When the switch receives a packet destined for another
subnet or VLAN, the switch looks at the routing table to determine where to forward
the packet. The packet is then passed to the VLAN interface of the destination. It is
then sent to the port where the end device is attached.
3. Use the VLAN Static Routing Wizard page to create a routing VLAN, configure the
IP address and subnet mask, and add the member ports.
For more information about this step, see Create a routing VLAN with the VLAN
static routing wizard on page 374.
