Table 45. LLDP-MED local device information (Continued)

Description

Field

The manufacturers name that is transmitted.

Manufacturer Name

The model name that is transmitted.

Model Name

The asset ID that is transmitted.

Asset ID

Location Information

Displays if a location TLV is present in LLDP-MED frames that are transmitted.

The type of location information that is transmitted.

Sub Type

The location information that is transmitted.

Location Information

Extended PoE

Displays if PoE device information is present in LLDP-MED frames that are transmitted.

The type of PoE device that is transmitted. The switch can supply PoE, so

it is a power sourcing equipment (PSE).

Device Type

The type of power source that is transmitted.

Power Source

The type of power priority that is transmitted.

Power Priority

The power in watts that is transmitted, that is, the information is

transmitted, not the actual power.

Power Value

Display the LLDP-MED remote device information

You can display LLDP-MED remote device information, which is information that the
device that is connected to an interface advertises.

To display the LLDP-MED remote device information:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.
