Table 46. LLDP-MED remote device information (Continued)

Description

Field

The type of power priority on the remote device.

Power Priority

The power in watts that the remote device transmits, that is, the

information is transmitted, not the actual power.

Power Value

Display the LLDP-MED remote device inventory

The LLDP inventory consists of the devices that LLDP detects and that support MED.

To display the LLDP-MED remote device inventory:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Select System > LLDP > LLDP-MED > Remote Device Inventory.

The Remote Device Inventory page displays.

6. To refresh the page, click the Refresh button.

The following table describes the nonconfigurable fields on the page.

Table 47. LLDP-MED remote device inventory information

Description

Field

The interface on the switch on which LLDP-MED information is received.

Port

The advertised management address of the remote device.

Management Address

The MAC address of the remote device.

MAC Address
