The Dynamic Binding Configuration table shows information about the DHCP
bindings that were learned on each interface on which DHCP snooping is enabled.
The following table describes the dynamic binding information.

Description

Field

The interface on which the DHCP client message was received.

Interface

The MAC address associated with the DHCP client that sent the message. This is

the key to the binding database.

MAC Address

The VLAN ID of the client interface.

VLAN ID

The IP address assigned to the client by the DHCP server.

IP Address

The remaining IP address lease time for the client.

Lease Time

11. To clear all dynamic bindings from the Dynamic Binding Configuration table, click

the Clear button.

12. To save the settings to the running configuration, click the Save icon.

Remove a static DHCP binding

You can remove a static binding from the DHCP snooping bindings database.

To remove a static DHCP binding:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Select Security > Control > DHCP Snooping > Binding Configuration.

The Binding Configuration page displays.

6. In the Static Binding Configuration table, select the check box for the static binding.

7. Click the Delete button.
