Table 143. RADIUS accounting server statistics information (Continued)
Description Field
The number of RADIUS packets of unknown type that were received from
this server on the accounting port. Unknown Types
The number of RADIUS packets that were received from this server on the
accounting port and dropped for some other reason. Packets Dropped
Modify the settings for a RADIUS accounting server on the switch To
modify the settings for a RADIUS accounting server on the switch:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login page displays.
3. Click the Main UI Login button.
The main UI login page displays in a new tab.
4. Enter admin as the user name, enter your local device password, and click the Login
button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The System Information page displays.
5. Select Security > Management Security > RADIUS > Accounting Server
Configuration.
The Accounting Server Configuration page displays.
6. Select the check box next to the server IP address.
7. Modify the configuration for the accounting server.
Note: If you change the selection from the Accounting Mode menu, the changes
are applied to all configured accounting servers, not just to the server for which you
selected the check box.
8. Click the Apply button.
Your settings are saved.
9. To save the settings to the running configuration, click the Save icon.
