Table 23. Green Ethernet local device information (Continued)

Description

Field

The receive DLL status, which indicates if the ‘rx system’ initialization is
complete and if port is ready to receive or update LLDPDUs that contain
EEE TLVs.

Rx_dll_ready

The time since the counters were reset.

Time Since Counters Last Cleared

Display green Ethernet information for the link partner of
an interface

The switch can detect green Ethernet information for the link partner of an interface,
that is for the remote device.

To display the green Ethernet information for the link partner of an interface:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Select System > Management > Green Ethernet > Green Ethernet Details.

The Green Ethernet Details page displays.

6. Scroll down to the Remote Device Information section.

7. From the Interface menu, select the interface.

The following table describes the nonconfigurable fields.
