Multiple steps are involved in defining a MAC ACL and applying it to the switch:

1. Create a MAC ACL ID (see Add a MAC ACL on page 654).

2. Create a MAC rule (see Configure MAC ACL rules on page 656).

3. Associate the MAC ACL with one or more interfaces (see Configure MAC bindings

on page 660).
You can display or delete MAC ACL configurations in the MAC binding table (see
Display or delete MAC ACL bindings in the MAC binding table on page 662).

Add a MAC ACL

To add a MAC ACL:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Select Security > ACL > Basic > MAC ACL.

The MAC ACL page displays.

The MAC ACL Table displays the number of ACLs currently configured on the switch
and the maximum number of ACLs that can be configured. The current size is equal
to the number of configured IPv4 and IPv6 ACLs plus the number of configured MAC
ACLs.

6. In the Name field, specify a name for the MAC ACL.

The name string can include alphabetic, numeric, hyphen, underscore, or space
characters only. The name must start with an alphabetic character.

7. Click the Add button.

The MAC ACL is added.

Each configured ACL displays the following information:

• Rules: The number of rules currently configured for the MAC ACL.
• Direction: The direction of packet traffic affected by the MAC ACL, which can be

Inbound or blank. (If the ACL is not bound to an interface, the direction is blank.)
