• VLAN only: Untagged frames and priority-tagged frames received on the interface

are discarded. VLAN-tagged frames are forwarded in accordance to the 802.1Q
VLAN specification.

• Admit All: Untagged frames and priority-tagged frames received on the interface

are accepted and assigned the value of the port VLAN ID for the interface.
VLAN-tagged frames are forwarded in accordance to the 802.1Q VLAN
specification.

• Admit Untagged Only: Untagged frames received on the interface are accepted.

VLAN-tagged frames are forwarded in accordance to the 802.1Q VLAN
specification.

12. From the Ingress Filtering menu, select one of the following options:

• Enabled: The frame is discarded if the interface is not a member of the VLAN with

which this frame is associated. In a tagged frame, the VLAN is identified by the
VLAN ID in the tag. In an untagged frame, the VLAN is the port VLAN ID of the
interface that receives this frame.

• Disabled: All frames are forwarded in accordance with the 802.1Q VLAN bridge

specification. The default is Disabled.

13. In the Port Priority field, specify the default 802.1p priority assigned to untagged

packets arriving at the port.
You can enter a number from 0 to 7.

14. Click the Apply button.

Your settings are saved.

15. To save the settings to the running configuration, click the Save icon.

The following table describes the nonconfigurable fields on the page.

Table 54. PVID configuration information

Description

Field

Indicates whether ingress filtering is enabled for the interface.

Current Ingress Filtering

The number of untagged VLANs that the interface is a member of.

Untagged VLANs

The number of tagged VLANs that the interface is a member of.

Tagged VLANs
