The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The System Information page displays.
5. Select Switching > STP > Advanced > MST Configuration.
The MST Configuration page display.
6. Configure the settings for the MST instance:
• MST ID: In the MST ID field, specify the ID of the MST. The ID can be in the range
from 1 to 4094.
• Priority: In the Priority field, specify the bridge priority value for the MST instance.
When switches or bridges are running STP, each is assigned a priority. After
exchanging BPDUs, the switch with the lowest priority value becomes the root
bridge. The bridge priority is a multiple of 4096. If you specify a priority that is not
a multiple of 4096, the priority is automatically set to the next lowest priority that
is a multiple of 4096. For example, if you set the priority to any value between 0
and 4095, the switch automatically sets the value to 0. The range is from 0 to
61440. The default is 32768.
• VLAN ID: From the VLAN ID menu, select the VLAN that must be associated with
the MST instance.
7. Click the Add button
The MST is added.
8. To save the settings to the running configuration, click the Save icon.
9. To refresh the page, click the Refresh button.
The following table describes the nonconfigurable fields on the page.
Table 60. MST configuration information
Description
Field
The bridge identifier for the MST instance, which is created by using the bridge
priority and the base MAC address of the bridge.
Bridge Identifier
The time in seconds since the topology of the MST instance changed.
Last TCN
The number of times the topology changed for the MST instance.
Topology Change Count
This field shows if a topology change is in progress on an interface in the MST.
(True or False.)
Topology Change
