Table 70. MLD snooping configuration information

Definition

Field

The number of multicast control frames that were processed.

Multicast Control Frame Count

The interface on which MLD snooping is administratively enabled. MLD

snooping must be enabled globally and on an interface for the interface

to be able to snoop MLD packets to determine which segments should

receive multicast packets directed to the group address.

Interfaces Enabled for MLD

Snooping

The VLAN on which MLD snooping is administratively enabled.

VLAN IDs Enabled For MLD

Snooping

Configure MLD snooping manually

You can manually configure the settings for MLD snooping, which is used to build
forwarding lists for IPv6 multicast traffic.

You can also configure MLD snooping automatically (see Configure MLD snooping
automatically with MLD Plus mode
on page 269).

To configure the settings for MLD snooping manually:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Select Switching > Multicast > MLD Snooping > Configuration.

The Configuration page displays.

6. Select the MLD Snooping Admin Mode Enable or Disable radio button to specify

the administrative mode for MLD snooping for the switch. The default is Disable.

7. Select the Proxy Querier Mode Enable or Disable radio button.
