8. In the Sequence Number field, optionally specify a number to indicate the order of

the access list relative to other access lists already assigned to the interface and
direction.
A low number indicates high precedence order. If a sequence number is already in
use for the interface and direction, the specified access list replaces the currently
attached access list using that sequence number. If you do not specify the sequence
number (meaning that the value is 0), a sequence number that is one number greater
than the highest sequence number currently in use for the interface and direction
is used. The range is from 1 to 4294967295.

9. To add the selected ACL to a port or LAG, in the Ports table or LAG table, click the

port or LAG so that a check mark displays.
You can add the ACL to several ports and LAGs.

The Ports and LAG tables display the available interfaces for ACL bindings.

10. Click the Apply button.

Your settings are saved.

11. To save the settings to the running configuration, click the Save icon.

The following table describes the nonconfigurable information displayed.

Table 164. Interface Binding Status information

Description

Field

The selected interface.

Interface

The selected packet filtering direction for the ACL.

Direction

The type of ACL assigned to the selected interface and direction.

ACL Type

The ACL number or name identifying the ACL assigned to the selected interface and
direction.

ACL ID/Name

The sequence number signifying the order of specified ACL relative to other ACLs
assigned to the selected interface and direction.

Sequence Number

Display or delete IP ACL bindings in the IP ACL binding
table

You can display or delete bindings for basic IPv4, extended IPv4, and IPv6 ACLs.
