4. Enter admin as the user name, enter your local device password, and click the Login
button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The System Information page displays.
5. Select Security > Traffic Control > Private VLAN > Private VLAN Host Interface
Configuration.
The Private VLAN Host Interface Configuration page displays.
6. Select whether to display physical interfaces, LAGs, or both by clicking one of the
following links above the table heading:
• 1 (the unit ID of the switch): Only physical interfaces are displayed. This is the
default setting.
• LAG: Only LAGs are displayed.
• All: Both physical interfaces and LAGs are displayed.
7. Select one or more interfaces by taking one of the following actions:
• To configure a single interface, select the check box associated with the port, or
type the port number in the Go To Interface field and click the Go button.
• To configure multiple interfaces with the same settings, select the check box
associated with each interface.
The interface that you select must be configured in Host mode (see Configure the
private VLAN port mode on page 581).
8. In the Host Primary VLAN field, specify a primary VLAN ID.
You can select a VLAN for which you configured the type as Primary (see Assign a
private VLAN type to a VLAN on page 578).
9. In the Host Secondary VLAN field, specify a secondary VLAN ID.
You can select a VLAN for which you configured the type as Isolated or Community,
both of which are secondary VLAN types within a private VLAN (see Assign a private
VLAN type to a VLAN on page 578).
10. Click the Apply button.
Your settings are saved.
The Operational VLAN(s) fields shows the primary and secondary VLANs that operate
on the host interface.
11. To save the settings to the running configuration, click the Save icon.
