NETGEAR AV Line M4250 GSM4210PX 8-Port Gigabit PoE+ Compliant Managed AV Switch with SFP (220W) - Manual (Page 449)

Table 129. MLD proxy interface statistics information (Continued)
Description Field
The number of MLD proxy leave messages received. Leaves Received
The number of MLD proxy leave messages sent. Leaves Sent
Display the MLD proxy membership and search the MLD
proxy membership database
You can display the MLD proxy membership information and search the MLD proxy
membership database by group.
To display the MLD proxy membership information and search the MLD proxy
membership database:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login page displays.
3. Click the Main UI Login button.
The main UI login page displays in a new tab.
4. Enter admin as the user name, enter your local device password, and click the Login
button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The System Information page displays.
5. Select Routing > IPv6 Multicast > MLD > Proxy Membership.
The Proxy Membership page displays.
6. To search for MLD proxy membership by group, specify the multicast group IPv6
address, and click the Go button.
If the entry exists, that entry with the matching group IPv6 address is displayed as
the first entry, followed by the remaining entries. An exact match is required.
7. To refresh the page, click the Refresh button.
The following table describes the nonconfigurable fields on the page.
Main User Manual 449 Configure Multicast Routing
AV Line of Fully Managed Switches M4250 Series Main User Manual
