8. Select the ICMP Redirects Enable or Disable radio button.

The default is Disable. If you enable ICMP Redirects, the switch can forward ICMP
Redirects.

9. In the ICMP Rate Limit Interval field, specify the number of ICMP error packets that

are allowed per burst interval.
By default, the burst interval is 1000 msec (the rate limit is 100 packets/sec). The
interval is from 0 to 2147483647 msec. Enter 0 to let the switch ignore the number
of ICMP error packets that are allowed per burst interval.

10. In the ICMP Rate Limit Burst Size field, specify the number of ICMP error packets

that are allowed for the burst size.
By default, the burst size is 100 packets. The burst size range is from 1 to 200. Enter
0 to let the switch ignore the number of ICMP error packets that are allowed for the
burst size.

11. To configure a global default gateway, select the Select to configure Global Default

Gateway check box. Then, in the Global Default Gateway field, enter the IP address.
The default gateway that you specify receives a higher preference than a default
gateway that is learned from a DHCP server. You configure one default gateway
only, but you can change the default gateway.

12. Click the Apply button.

Your settings are saved.

13. To save the settings to the running configuration, click the Save icon.

The following table describes the nonconfigurable fields on the page.

Table 93. IPv4 routing configuration information

Description

Field

The default value inserted into the Time-To-Live field of the IP header of
datagrams originated by the switch, if a TTL value is not supplied by the
transport layer protocol.

Default Time to Live

The maximum number of hops supported by the switch.

Maximum Next Hops
