If you are changing an existing ARP entry, click the Apply button.

Your settings are saved.

10. To save the settings to the running configuration, click the Save icon.

The ARP table can be large. The pagination navigation menu functions as follows:

Rows per page: Select how many table entries are displayed per page. Possible

values are 20, 50, 100, 200, and All. If you select All, the browser might be slow to
display the information.

<. Display the previous page of the table data entries.

>. Display the next page of the table data entries.

The following table describes the nonconfigurable fields on the page.

Table 103. ARP cache information

Description

Field

The IP address of the device.

IP Address

The associated interface (in the unit/port format) for the device connection.

Port

The unicast MAC address of the device.

MAC Address

The type of ARP entry. Possible values are as follows:
Local: An ARP entry associated with one of the switch’s routing

interface’s MAC addresses.

Gateway: A dynamic ARP entry for which the IP address is that of a

router.

Static: An ARP entry that you added.

Dynamic: An ARP entry that was learned by the switch.

Type

The time (in seconds) since the entry was last refreshed in the ARP table.

Age

Delete a static ARP entry

You can delete a static ARP entry that you no longer need.

To delete a static ARP entry:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

Main User Manual

380

Manage Routing

AV Line of Fully Managed Switches M4250 Series Main User Manual
