10. Click the Apply button.

Your settings are saved.

11. To save the settings to the running configuration, click the Save icon.

12. To refresh the information on the page, click the Refresh button.

The following table describes the nonconfigurable fields on the page.

Table 33. DHCP relay status information

Description

Field

The total number of DHCP requests received from all clients since the time the

switch was started.

Requests Received

The total number of DHCP requests forwarded to the server since the time the

switch was started.

Requests Relayed

The total number of DHCP packets discarded by the relay agent since the time

the switch was started.

Packets Discarded

DHCP Layer 2 relay

If you enable and configure a DHCP relay agent on the switch, some Layer 2 (L2) devices
do not need to connect to a DHCP server on the physical network. A relay agent
automatically populates the gateway IP address (giaddr) field and adds the Relay Agent
Information option to DHCP messages. A DHCP server uses this option for IP addresses
and other assignment policies. A DHCP relay agent is usually an IP routing-aware device,
which is also referred to as a Layer 3 relay agent. In some network configurations, L2
devices must append the Relay Agent Information option because they are closer to
the end hosts.

An L2 device can operate as a bridge only for a network and might not include an IPv4
address on the network. If an L2 device lacks an IPv4 source address, the device cannot
relay packets directly to a DHCP server that is located on another network. In that
situation, the L2 device can append the Relay Agent Information option and broadcast
the DHCP message.
