M4250-12m2xf (sku msm4214x), M4250-16xf (sku xsm4216f) – NETGEAR AV Line M4250 GSM4210PX 8-Port Gigabit PoE+ Compliant Managed AV Switch with SFP (220W) User Manual

Page 824

background image

Table 191. Hardware technical specifications for model M4250-40G8XF-PoE++

Description

Feature

40 PoE++ (802.3bt) 1GBASE-T RJ-45 ports
Eight 10G SFP+ fiber uplink ports

Network interfaces

100–240V ~ 50–60Hz, 12A for each PSU

AC power input

1 PSU: 912W - 3113.57 BTU/hr
2 PSUs: 1998W - 6821.17 BTU/hr,
3 PSUs: 3523W - 12027.52 BTU/hr
82.6W - 282 BTU/hr
68.5W - 233.86 BTU/hr

Max PoE
No PoE
Standby

Power
consumption

2880W with 3 PSUs

PoE power budget

17.32 in (440 mm)
3.40 in (86.4 mm), 2U
13.78 in (350 mm)

Width
Height
Depth

Dimensions

22.72 lb (10.280 kg)

Weight

M4250-12M2XF (SKU MSM4214X)

The following table shows the specifications that are specific to model M4250-12M2XF.

Table 192. Hardware technical specifications for model M4250-12M2XF

Description

Feature

Twelve 2.5GBASE-T RJ-45 ports
Two 10G SFP+ fiber uplink ports

Network interfaces

100–240V ~ 50–60Hz, 1.2–0.6A

AC power input

37.9W - 129.39 BTU/hr
14.1W - 48.14 BTU/hr

Max load
Standby

Power
consumption

17.32 in (440 mm)
1.70 in (43.2 mm), 1U
3.94 in (100 mm)

Width
Height
Depth

Dimensions

3.85 lb (1.745 kg)

Weight

M4250-16XF (SKU XSM4216F)

The following table shows the specifications that are specific to model M4250-16XF.

Main User Manual

824

Software Default Settings and
Hardware Specifications

AV Line of Fully Managed Switches M4250 Series Main User Manual
