Table 41. LLDP statistics information (Continued)

Description

Field

The number of LLDP frames transmitted by the LLDP agent.

Transmit Total

The number of valid LLDP frames received by this LLDP agent.

Receive Total

The number of LLDP TLVs discarded for any reason by the LLDP agent.

Discards

The number of invalid LLDP frames received by the LLDP agent.

Errors

The number of age-outs that occurred. An age-out is the number of times
the complete set of information advertised by a particular MAC Service
Access Point (MSAP) was deleted from tables associated with the remote
entries because information timeliness interval expired.

Ageouts

The number of LLDP TLVs discarded by the LLDP agent.

TLV Discards

The number of LLDP TLVs received that were not recognized by the LLDP
agent.

TLV Unknowns

The total number of LLDP-MED TLVs received.

TLV MED

The total number of LLDP TLVs received that are of type 802.1.

TLV 802.1

The total number of LLDP TLVs received that are of type 802.3.

TLV 802.3

The total number of LLDP TLVs received that are of type UPOE.

TLV UPOE

The total number of LLDP TLVs received that are of type NTGR.

TLV NTGR

Display LLDP local device information

You can display LLDP local device information, which is information that the switch itself,
or an interface of the switch, advertises.

To display LLDP local device information:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.
