Table 7. Device Status

Description

Field

The release, version, and maintenance number of the firmware running

on the switch. For example, if the release is 1, the version is 2, and the

maintenance number is 4, the format is 1.2.4.

Firmware Version

The version of the boot code that is in the flash memory to load the

firmware into the memory.

Boot Version

The version of the software for the complex programmable logic device

(CPLD ) on the switch.

CPLD Version

The serial number of the switch.

Serial Number

The status of the power supply in the switch:

Operational: The power supply is present and functioning properly.

Failed: The power supply is present, but the power cable is not plugged

in or a defective cable is plugged in.

PS-1

The PoE system status on the switch:

ON: Less than 10W of PoE power is available for another PD.

OFF: At least 10W of PoE power available for another PD.

N/A: PoE is not supported by the switch.

MAX PoE

The time in days, hours, and minutes since the switch was restarted.

System Up Time

View the system CPU status

To view the system CPU status:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.
