Table 93. IPv4 routing configuration information (Continued)
Description
Field
The maximum number of routes supported by the switch.
Maximum Routes
The maximum number of static routes supported by the switch.
Maximum Static Routes
Display the IPv4 statistics
You can display the IPv4 routing statics for the switch.
To display the IPv4 routing statistics for the switch:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login page displays.
3. Click the Main UI Login button.
The main UI login page displays in a new tab.
4. Enter admin as the user name, enter your local device password, and click the Login
button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The System Information page displays.
5. Select Routing> IP > Basic > Statistics.
The Statistics page displays.
The following table describes the nonconfigurable fields on the page.
Table 94. IP statistics information
Description
Field
The total number of input datagrams received from interfaces, including
those received in error.
IpInReceives
The number of input datagrams discarded due to errors in their IP
headers, including bad checksums, version number mismatch, other
format errors, time-to-live exceeded, errors discovered in processing
their IP options, and so on.
IpInHdrErrors
