The following table describes the nonconfigurable information that is displayed.

Table 161. Interface Binding Status information

Description

Field

The selected interface.

Interface

The selected packet filtering direction for the ACL.

Direction

The type of ACL assigned to the selected interface and direction.

ACL Type

The ACL number or name identifying the ACL assigned to the selected interface and
direction.

ACL ID

The sequence number signifying the order of specified ACL relative to other ACLs
assigned to the selected interface and direction.

Sequence Number

Display or delete MAC ACL bindings in the MAC binding
table

You can display or delete the MAC ACL bindings in the MAC binding table.

To display or delete MAC ACL bindings:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Select Security > ACL > Basic > Binding Table.

The Binding Table page displays. This table displays the MAC ACL-to-interface
bindings.
