Proxy Querier

Report Flood Mode

Exclude Mrouter Interface Mode

Installs reserved Multicast MAC addresses into the system.

If disabled, these IGMP snooping modes are automatically disabled for the VLAN.

Note: For information about other settings on the page, see Configure IGMP
snooping for VLANs manually
on page 260.

8. Click the Apply button.

Your settings are saved.

9. To save the settings to the running configuration, click the Save icon.

Configure IGMP snooping for VLANs manually

You can manually configure the settings for IGMP snooping for VLANs, which is used
to build forwarding lists for multicast traffic.

You can also configure IGMP snooping for VLANS automatically (see Configure IGMP
snooping for VLANs automatically with IGMP Plus mode
on page 259).

To configure the settings for IGMP snooping for a VLAN manually:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Select Switching > Multicast > IGMP Snooping > IGMP VLAN Configuration.

The IGMP VLAN Configuration page displays.

6. Select the check box next to the VLAN ID.
