Remove a static ip source guard binding – NETGEAR AV Line M4250 GSM4210PX 8-Port Gigabit PoE+ Compliant Managed AV Switch with SFP (220W) User Manual
Page 618
The Dynamic Binding Configuration table shows information about the IPSG bindings
that were learned on each interface on which IPSG is enabled. The following table
describes the dynamic binding information.
Description
Field
The interface on which the IPSG source binding was learned.
Interface
The MAC address associated with the IPSG source device. This is the key to the
binding database.
MAC Address
The VLAN ID for the interface of the IPSG source device.
VLAN ID
The IP address of the IPSG source device.
IP Address
The filter type used on the switch interface. Either IPSG is configured to function with
the source IP address only or, if port security is also enabled for IPSG, with both the
source IP address and MAC address.
Filter Type
11. To save the settings to the running configuration, click the Save icon.
12. To clear all dynamic bindings from the Dynamic Binding Configuration table, click
the Clear button.
13. To save the settings to the running configuration, click the Save icon.
Remove a static IP source guard binding
You can remove a static binding from the IP source guard (IPSG) bindings database.
To remove a static IPSG binding:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login page displays.
3. Click the Main UI Login button.
The main UI login page displays in a new tab.
4. Enter admin as the user name, enter your local device password, and click the Login
button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The System Information page displays.
5. Select Security > Control > IP Source Guard > Binding Configuration.
Main User Manual
618
Manage Switch Security
AV Line of Fully Managed Switches M4250 Series Main User Manual
