• 6 Src/Dest IP and TCP/UDP Port fields: Source and destination IP addresses
and source and destination TCP/UDP port fields of the packet.
7. Click the Apply button.
Your settings are saved.
8. To save the settings to the running configuration, click the Save icon.
Configure the LAG settings
You can group one or more full-duplex Ethernet links to be aggregated together to
form a link aggregation group, which is also known as a port-channel. The switch treats
the LAG as if it were a single link.
To configure the LAG settings:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login page displays.
3. Click the Main UI Login button.
The main UI login page displays in a new tab.
4. Enter admin as the user name, enter your local device password, and click the Login
button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The System Information page displays.
5. Select Switching > LAG > LAG Configuration.
The LAG Configuration page displays.
6. To change the default name of the LAG, in the LAG Name field, enter the name to
be assigned to the LAG.
By default, the names are ch1, ch2, ch3, and so on. You can enter a name of up to
15 characters.
For information about adding a name in the Description field, see Add port, LAG,
and VLAN descriptions on page 297 or Configure a single LAG and its membership
on page 307.
7. From the Admin Mode menu, select to enable or disable the LAG.
When the LAG is disabled, no traffic flows and LACPDUs are dropped, but the links
that form the LAG are not released. The default is Enable.
