Table 49. ISDP global configuration information
Description
Field
The time that the information in the neighbors table was changed.
Neighbors table last time
changed
The device ID of this switch.
Device ID
The device ID format capability.
Device ID Format Capability
The device ID format.
Device ID Format
Configure ISDP settings for an interface
You can configure if an interface can communicate IDSP packets.
To configure ISDP settings for an interface:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login page displays.
3. Click the Main UI Login button.
The main UI login page displays in a new tab.
4. Enter admin as the user name, enter your local device password, and click the Login
button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The System Information page displays.
5. Select System > ISDP > Advanced > Interface Configuration.
The Interface Configuration page displays.
6. Select one or more interfaces by taking one of the following actions:
• To configure a single interface, select the check box associated with the interface,
or type the interface number in the Go To Interface field and click the Go button.
• To configure multiple interfaces with the same settings, select the check box
associated with each interface.
• To configure all interfaces with the same settings, select the check box in the
heading row.
