Table 115. IGMP proxy interface statistics information (Continued)
Description
Field
The number of IGMP leave messages received.
Leaves Received
The number of IGMP leave messages sent.
Leaves Sent
Display the IGMP proxy membership and search the IGMP
proxy membership database
You can display the IGMP proxy membership information and search the IGMP proxy
membership database by group.
To display the IGMP proxy membership information and search the IGMP proxy
membership database:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login page displays.
3. Click the Main UI Login button.
The main UI login page displays in a new tab.
4. Enter admin as the user name, enter your local device password, and click the Login
button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The System Information page displays.
5. Select Routing > Multicast > IGMP > Proxy Membership.
The Proxy Membership page displays.
6. To search for IGMP proxy membership by group, specify the multicast group IPv4
address, and click the Go button.
If the entry exists, that entry with the matching group IPv4 address is displayed as
the first entry, followed by the remaining entries. An exact match is required.
7. To refresh the page, click the Refresh button.
The following table describes the nonconfigurable fields on the page.
