Table 23. Green Ethernet local device information

Description

Field

The cumulative energy saved on the port because of the green modes
that are enabled on the port in watts * hours.

Cumulative Energy Saved on this
port due to Green mode(s) (Watts
* Hours)

The operational state (Active or Inactive) of the Energy Detect mode.

Energy Detect Operational Status

The reason for the operational state that is displayed in the previous field.

Reason

The total number of times that the port entered the low-power idle (LPI)
state since the EEE counters were reset.

Rx Low Power Idle Event Count

The total period (in 10 us increments) that the port remained in the LPI
state since the EEE counters were reset.

Rx Low Power Idle Duration (uSec)

The total number of times that the link partner of the port entered the LPI
state since the EEE counters were reset.

Tx Low Power Idle Event Count

The total period (in 10 us increments) that the link partner of the port
remained in the LPI state since the EEE counters were reset.

Tx Low Power Idle Duration (uSec)

The value of ‘Tw_sys’ that the port can support.

Tw_sys_tx (uSec)

The link partner’s ‘transmit Tw_sys’ that the port uses to compute the
‘Tw_sys’ that it requests from its link partner.

Tw_sys_tx Echo (uSec)

The value of ‘Tw_sys’ that the port requested from its link partner.

Tw_sys_rx (uSec)

The link partner’s ‘receive Tw_sys’ that the port uses to compute the
‘Tw_sys’ that it can support.

Tw_sys_rx Echo (uSec)

The value of the ‘fallback Tw_sys’ that the port requested from its link
partner.

Fallback Tw_sys (uSec)

The initialization status of the transmit EEE transmit Data Link Layer (DLL)
function on the port.

Tx_dll_enabled

The transmit DLL status, which indicates if the ‘tx system’ initialization is
complete and if port is ready to receive or update LLDPDUs that contain
EEE TLVs.

Tx_dll_ready

The status of the EEE capability negotiation on the port.

Rx_dll_enabled
