Table 167. Port detailed statistics information (Continued)

Description

Field

The total number of packets that higher-level protocols requested be
transmitted to a multicast address, including those that were discarded or not
sent.

Multicast Packets
Transmitted

The total number of packets that higher-level protocols requested be
transmitted to the broadcast address, including those that were discarded or
not sent.

Broadcast Packets
Transmitted

The total number of outbound packets that were discarded even though no
errors were detected that would prevent the packets from being delivered to
a higher-layer protocol.
A possible reason for discarding a packet could be to free up buffer space.

Transmit Packets Discarded

The sum of single, multiple, and excessive collisions.

Total Transmit Errors

The total number of transmitted packets with a length (excluding framing bits
but including FCS octets) between 64 and 1518 octets, inclusive, and with a
bad Frame Check Sequence (FCS) with an integral number of octets.

Tx FCS Errors

The sum of single collision frames discarded, multiple collision frames
discarded, and excessive frames discarded.

Total Transmit Packets
Discarded

The number of successfully transmitted frames on a particular interface for
which transmission is inhibited by exactly one collision.

Single Collision Frames

The number of successfully transmitted frames on a particular interface for
which transmission is inhibited by more than one collision.

Multiple Collision Frames

The number of frames for which transmission on a particular interface fails due
to excessive collisions.

Excessive Collision Frames

The number of STP BPDUs received at the selected port.

STP BPDUs Received

The number of STP BPDUs transmitted from the selected port.

STP BPDUs Transmitted

The number of RSTP BPDUs received at the selected port.

RSTP BPDUs Received

The number of RSTP BPDUs transmitted from the selected port.

RSTP BPDUs Transmitted

The number of MSTP BPDUs received at the selected port.

MSTP BPDUs Received

The number of MSTP BPDUs transmitted from the selected port.

MSTP BPDUs Transmitted

The number of MAC control frames transmitted on this interface with an opcode
indicating the PAUSE operation. This counter does not increment when the
interface is operating in half-duplex mode.

802.3x Pause Frames
Transmitted

The number of GVRP PDUs received in the GARP Layer.

GVRP PDUs Received

The number of GVRP PDUs transmitted from the GARP Layer.

GVRP PDUs Transmitted

The number of times attempted GVRP registrations could not be completed.

GVRP Failed Registrations

The number of GMRP PDUs received from the GARP Layer.

GMRP PDUs Received
