Table 108. Multicast IPv4 Mroute table information

Description

Field

The destination group IPv4 address.

Group IP

The IPv4 address of the multicast packet source to be combined with the group

IPv4 to fully identify a single route.

Source IP

The incoming interface on which multicast packets for this source/group arrive.

Incoming Interface

The list of outgoing interfaces on which multicast packets for this source/group

are forwarded.

Outgoing Interfaces

The time in seconds since the entry was created.

Up Time (hh:mm:ss)

The time in seconds before this entry ages out and is removed from the table.

Expiry Time (hh:mm:ss)

The IPv4 address of the reverse path forwarding (RPF) neighbor.

RPF Neighbor

The multicast routing protocol which dynamically created this entry. The possible

values are as follows:

• PIM-DM

• PIM-SM

Protocol

The value displayed in this field is valid if the multicast routing protocol is PIM-SM.

The possible values are RPT and SPT. For other protocols a “------” is displayed.

Flags

Add static multicast entries to the IPv4 Mroute table

You can add a static multicast entry to the IPv4 Mroute table.

To add a static multicast entry to the IPv4 Mroute table:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.

Main User Manual

395

Configure Multicast Routing

AV Line of Fully Managed Switches M4250 Series Main User Manual
