Page 191
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The System Information page displays.
5. Select Switching > VLAN > Basic > VLAN Configuration.
The VLAN Configuration page displays.
6. In the VLAN Configuration section, specify the settings for the new VLAN:
• VLAN ID: Specify the identifier for the new VLAN.
The range of the VLAN ID can be from 1 to 4093.
• VLAN Name: Type a name for new VLAN.
The name can be up to 32 characters, including blanks.
By default, the name for VLAN ID 1 is Default.
Note: When you add a VLAN manually (as in this procedure), the VLAN Type field
always shows Static. A VLAN that is created by GVRP registration initially uses a type
of dynamic but you can change it to static (see Change a VLAN on page 191). The
type of the default VLAN (VLAN ID 1) is always Default.
7. Click the Add button.
The VLAN is added.
8. To save the settings to the running configuration, click the Save icon.
Change a VLAN
You can change the name for a statically or dynamically added
VLAN. For a dynamically added VLAN (for example, a VLAN that is created by GVRP
registration), you change the VLAN type to static.
To change a VLAN:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login page displays.
3. Click the Main UI Login button.
The main UI login page displays in a new tab.
4. Enter admin as the user name, enter your local device password, and click the Login
button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The System Information page displays.
5. Select Switching > VLAN > Basic > VLAN Configuration.
