3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Select Routing> IPv6 > Basic > Route Table.

The Route Table page displays.

6. From the Routes Displayed menu, select which routes must be displayed in the

table:

• All Routes: All active IPv6 routes.
• Best Routes Only: The best active routes only,
• Configured Routes Only: The manually configured routes only.

7. To refresh the page, click the Refresh button.

The following table describes the nonconfigurable fields on the page.

Table 97. IPv6 route table information

Description

Field

The total number of active routes in the route table.

Number of Routes

The network prefix for the active route.

IPv6 Prefix

The prefix length for the active route.

Prefix Length

The type of protocol for the active route.

Protocol

The interface over which the route is active. For a reject route, the next

hop is a null (Null0) interface.

Next Hop Interface

The next hop IPv6 address for the active route.

Next Hop IP Address

The route preference of the configured route.

Preference

Configure IPv6 routing interfaces

You can configure one or more IPv6 routing interfaces.
