Table 5. Fan Status (Continued)

Description

Field

The description of the fan (FAN-1, FAN-2, or FAN-3).

Description

The type of fan is always Fixed.

Type

The speed of the fan.

For more information, see the hardware installation guide, which you can

download by visiting netgear.com/support/download/.

Speed

The duty level of the fan in percentage.

Duty Level

The status of the fan:

Operational: The fan is running normally.

Failure: The fan failed.

Not Present: The fan is not present. (The number of fans depends on

the switch model.)

Stop: The fan stopped because the switch temperature is low. The fan

will start if the switch temperature rises.

FAN Status

View the temperature sensor information

You can view the current temperature of different system sensors using the Temperature
Status table.

To view temperature information:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Scroll down to the Temperature Status section.
