Your settings are saved.

13. To save the settings to the running configuration, click the Save icon.

The following table describes the nonconfigurable fields on the page.

Table 105. RIP configuration information

Description

Field

The number of route changes made to the IP route database by RIP. This
does not include the refreshing of a route after it aged out.

Global Route Changes

The number of responses sent to RIP queries from other devices.

Global Queries

Configure RIP interface settings

You can configure RIP settings that apply to individual interfaces.

To configure RIP interface settings:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Select Routing > RIP > Advanced > Interface Configuration.

The Interface Configuration page displays.

6. Select whether to display physical interfaces, VLANs, or both by clicking one of the

following links above the table heading:

• 1: Only physical interfaces are displayed. This is the default setting.
• VLANS: Only VLANs are displayed.
• All: Both physical interfaces and VLANs are displayed.

7. Select one or more interfaces by taking one of the following actions:
