11. To save the settings to the running configuration, click the Save icon.

Display DHCP L2 relay interface statistics

To display the DHCP L2 relay interface statistics:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Select System > Services > DHCP L2 Relay > DHCP L2 Relay Interface Statistics.

The DHCP L2 Relay Interface Statistics page displays.

6. Select whether to display physical interfaces, LAGs, or both by clicking one of the

following links above the table heading:

• 1: Only physical interfaces are displayed. This is the default setting.
• VLANS: Only VLANs are displayed.
• LAG: Only LAGs are displayed.
• All: Both physical interfaces and LAGs are displayed.

7. To refresh the information on the page, click the Refresh button.

The following table describes the nonconfigurable fields on the page.

Table 34. DHCP L2 relay interface statistics information

Description

Field

The interface from which the DHCP message is received.

Interface

The number of DHCP messages with Option 82 received from an untrusted

server.

UntrustedServerMsgsWithOpt82

Main User Manual

116

Configure Switch System
Information

AV Line of Fully Managed Switches M4250 Series Main User Manual
