6. To delete a MAC ACL-to-interface binding, do the following:

a. Select the check box next to the interface.

b. Click the Delete button.

The binding is removed.

7. To save the settings to the running configuration, click the Save icon.

The following table describes the information that is displayed in the MAC binding
table.

Table 162. MAC Binding Table information

Description

Field

The interface of the ACL assigned.

Interface

The selected packet filtering direction for the ACL.

Direction

The type of ACL assigned to selected interface and direction.

ACL Type

The ACL name identifying the ACL assigned to selected interface and direction.

ACL ID

The sequence number signifying the order of the specified ACL relative to other ACLs
assigned to selected interface and direction.

Sequence Number

Configure a basic or extended IPv4 ACL

An IPv4 ACL consists of a set of rules that are matched sequentially against a packet.
When a packet meets the match criteria of a rule, the specified rule action (Permit or
Deny) is taken, and the additional rules are not checked for a match. You must specify
the interfaces to which an IPv4 ACL applies, as well as whether it applies to inbound or
outbound traffic.
