Table 68. Querier VLAN configuration information

Description

Field

The operational state of the IGMP snooping querier on a VLAN:
Querier: The snooping switch is the querier in the VLAN. The snooping

switch sends out periodic queries with a time interval equal to the
configured querier query interval. If the snooping switch finds a better
querier in the VLAN, it moves to non-querier mode.

Non-Querier: The snooping switch is innNon-querier mode in the

VLAN. If the querier expiry interval timer expires, the snooping switch
moves into querier mode.

Disabled: The snooping querier is not operational on the VLAN. The

snooping querier moves to disabled mode when IGMP snooping is
not operational on the VLAN or when the querier address is not
configured or the network management address is also not configured.

Operational State

The operational IGMP protocol version of the querier.

Operational Version

The IP address of the last querier from which a query was snooped on
the VLAN.

Last Querier Address

The IGMP protocol version of the last querier from which a query was
snooped on the VLAN.

Last Querier Version

The maximum response time to be used in the queries that are sent by
the snooping querier.

Operational Max Response Time

Remove the IGMP snooping querier settings for a VLAN

You can remove the IGMP snooping querier settings for a VLAN.

To remove the IGMP snooping querier settings for a VLAN:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.
