Table 165. Interface Binding Status information (Continued)
Description
Field
The ACL number or name identifying the ACL assigned to the selected interface and
direction.
ACL ID/Name
The sequence number signifying the order of specified ACL relative to other ACLs
assigned to the selected interface and direction.
Sequence Number
Configure VLAN ACL bindings
You can associate a MAC ACL, any type of IPv4 ACL, or an IPv6 ACL with a VLAN. When
you do so, the ACL is applied to all interfaces that are members of the VLAN.
Add a VLAN ACL binding
To add a VLAN ACL binding:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login page displays.
3. Click the Main UI Login button.
The main UI login page displays in a new tab.
4. Enter admin as the user name, enter your local device password, and click the Login
button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The System Information page displays.
5. Select Security > ACL> Advanced > VLAN Binding Table.
The VLAN Binding Table page displays.
6. In the VLAN ID field, enter the VLAN ID to which the binding must apply.
7. From the Direction menu, select the packet filtering direction for the ACL:
• Inbound: The rule is applied to traffic entering the port.
• Outbound: The rule is applied to traffic leaving the port.
8. In the Sequence Number field, optionally specify a number to indicate the order of
the access list relative to other access lists already assigned to the VLAN and direction.
A low number indicates high precedence order. If a sequence number is already in
use for the VLAN ID and direction, the specified access list replaces the currently
attached access list using that sequence number. If you do not specify the sequence
number (meaning that the value is 0), a sequence number that is one number greater
