7. To refresh the page, click the Refresh button.
The following table describes the nonconfigurable fields on the page.
Table 118. IPv4 PIM neighbor information
Description
Field
The interface on which the PIM neighbor is connected.
Interface
The IPv4 address of the PIM neighbor.
Neighbor IP
The time that passed since the PIM device became a neighbor of the
interface.
Up Time (hh:mm:ss)
The time remaining before the PIM neighbor ages out.
Expiry Time (hh:mm:ss)
The designated router (DR) priority of the PIM neighbor.
DR Priority
Add an IPv4 PIM candidate rendezvous point configuration
You can add an IPv4 PIM candidate rendezvous point (RP) configuration on an interface.
To add an IPv4 PIM candidate RP configuration:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login page displays.
3. Click the Main UI Login button.
The main UI login page displays in a new tab.
4. Enter admin as the user name, enter your local device password, and click the Login
button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The System Information page displays.
5. Select Routing > Multicast > PIM > Candidate RP Configuration.
The Candidate RP Configuration page displays.
6. From the Interface menu, select the interface.
7. In the Group Address field, specify the group IPv4 address that is transmitted in
candidate-RP-advertisements.
