6. To refresh the page, click the Refresh button.

The following table describes the nonconfigurable Temperature Status information.

Table 6. Temperature Status information

Description

Field

The unit ID of the switch in which the sensor is installed. This ID is always

1.

Unit ID

The ID of the sensor.

Sensor

The description of the sensor.

Description

The temperature of the sensor in Celsius.

Temperature (C)

The state of the sensor: Operational or Failure.

State

The maximum supported operating temperature in Celsius.

Max Temp (C)

View the device status and firmware version

You can view the device status and firmware version.

To view the device status and firmware version:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Scroll down to the Temperature Status section.

6. To refresh the page, click the Refresh button.

The following table describes the nonconfigurable Device Status information.
