background image

Table 8. Switch statistics information (Continued)

Description

Field

The largest number of VLANs that were active on this switch since the
last reboot.

Most VLAN Entries Ever Used

The number of presently active VLAN entries on this switch that were
created statically.

Static VLAN Entries

The number of presently active VLAN entries on this switch that were
created by GVRP registration.

Dynamic VLAN Entries

The number of VLANs on this switch that were created and then deleted
since the last reboot.

VLAN Deletes

The elapsed time, in days, hours, minutes, and seconds, since the
statistics for this switch were last cleared.

Time Since Counters Last Cleared

View USB device information

To display the USB device information:

1. Launch a web browser.

2. In the address field of your web browser, enter the IP address of the switch.

The login page displays.

3. Click the Main UI Login button.

The main UI login page displays in a new tab.

4. Enter admin as the user name, enter your local device password, and click the Login

button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.

The System Information page displays.

5. Select System > Management > USB Device Information.

The USB Device Information page displays.

The Device Status field displays the current status of the device. The status is one of
the following:

• Active: The device is USB plugged in and recognized by the switch.
• Inactive: The device is not mounted.
• Invalid: The device is not present or an invalid device is plugged in.

6. To refresh the page, click the Refresh button.
