You can either select a mirror interface or a redirect interface. These options are
mutually exclusive.
• Redirect Interface: From the menu, select the egress interface to which the
matching traffic stream must be redirected, bypassing any forwarding decision
normally performed by the switch.
You can either select a redirect interface or a mirror interface. These options are
mutually exclusive.
• Src IP Address: Specify an IP address using dotted-decimal notation to be
compared to a packet’s source IP address as a match criterion for the selected IP
ACL rule.
• Src IP Mask: Specify the IP mask in dotted-decimal notation to be used with the
source IP address.
• Rate Limit Conform Data Rate: Specify the value of the conforming data rate,
which is the data rate at which confirming traffic is limited. The range is from 1 to
4294967295 Kbps.
• Rate Limit Burst Size: Specify the value of the burst size, which is the size at which
bursts of traffic above the confirming data rate are permitted. The range is from
1 to 128 Kbps.
• Time Range: From the Time Range menu, select the timer schedule that must
be associated with the rule. For more information about timer schedules, see
Timer schedules on page 144. If you did not set up any timer schedules, the menu
does not present any options.
9. Click the Apply button.
Your settings are saved.
The Rule Status field in the table shows if the rule is active or inactive. Blank means
that no timer schedule is associated with the rule.
10. To save the settings to the running configuration, click the Save icon.
Modify the match criteria for a basic IPv4 ACL rule
To modify the match
criteria for a basic IPv4 ACL rule:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login page displays.
3. Click the Main UI Login button.
The main UI login page displays in a new tab.
4. Enter admin as the user name, enter your local device password, and click the Login
button.
