5. On the Policy Configuration page, create a new policy with the following settings:
• Policy Selector: Policy1
• Member Class: Class1
For more information about this page, see Configure a DiffServ policy on page 480.
6. Click the Add button.
The policy is added.
7. Click the Policy1 hyperlink to display the Policy Class Configuration page for this
policy.
8. Configure the Policy attributes as follows:
• Assign Queue: 3
• Policy Attribute: Simple Policy
• Color Mode: Color Blind
• Committed Rate: 1000000 Kbps
• Committed Burst Size: 128 KB
• Confirm Action: Send
• Violate Action: Drop
For more information about this page, see Configure a DiffServ policy on page 480.
9. On the Service Configuration page, select the check box next to interfaces 7 and 8
to attach the policy to these interfaces, and then click the Apply button. (See
Configure the DiffServ service interface on page 489.)
All UDP packet flows destined to the 192.12.2.0 network with an IP source address from
the 192.12.1.0 network that include a Layer 4 Source port of 4567 and Destination port
of 4568 from this switch on ports 7 and 8 are assigned to hardware queue 3.
On this network, traffic from streaming applications uses UDP port 4567 as the source
and 4568 as the destination. This real-time traffic is time sensitive, so it is assigned to a
high-priority hardware queue. By default, data traffic uses hardware queue 0, which is
designated as a best-effort queue.
Also the
confirmed action
on this flow is to send the packets with a committed rate of
1000000 Kbps and burst size of 128 KB. Packets that violate the committed rate and
burst size are dropped.
802.1X access control
Local Area Networks (LANs) are often deployed in environments that permit unauthorized
devices to be physically attached to the LAN infrastructure, or permit unauthorized users
