NETGEAR AV Line M4250 GSM4210PX 8-Port Gigabit PoE+ Compliant Managed AV Switch with SFP (220W) User Manual
Page 250
4. Enter admin as the user name, enter your local device password, and click the Login
button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The System Information page displays.
5. Select Switching > Multicast > MFDB > MFDB Table.
The MFDB Table page displays.
6. To search for an entry, in the Search by MAC Address, enter a MAC address, and
click the Go button.
If the address exists, that entry is displayed. An exact match is required.
The following table describes the nonconfigurable fields on the page.
Table 64. MFDB information
Description
Field
The multicast MAC address for which you requested data.
MAC Address
The VLAN ID to which the multicast MAC address is related.
VLAN ID
The component that is responsible for this entry in the MFDB. The
component can be IGMP snooping, GMRP, Static Filtering, or MLD
snooping.
Component
The type of the entry. Static entries are those that you configure. Dynamic
entries are added to the table as a result of a learning process or protocol.
Type
The description of this multicast table entry. The description can be
Management Configured, Network Configured, or Network Assisted.
Description
The forwarding list that is derived from combining all the forwarding
interfaces and removing the interfaces that are listed as the static filtering
interfaces.
Forwarding Interfaces
Remove the IGMP snooping entries from the multicast
forwarding database
You can remove the IGMP snooping entries from the multicast forwarding database.
Main User Manual
250
Configure Switching Information
AV Line of Fully Managed Switches M4250 Series Main User Manual
