The CST Port Status page displays.

6. Select whether to display physical interfaces, LAGs, or both by clicking one of the

following links above the table heading:

• 1: Only physical interfaces are displayed. This is the default setting.
• LAG: Only LAGs are displayed.
• All: Both physical interfaces and LAGs are displayed.

7. To refresh the page, click the Refresh button.

The following table describes the nonconfigurable fields on the page.

Table 59. CST interface status information

Description

Field

The physical interface or LAG that is associated with the CST.

Interface

The port identifier for port in the CST, which is created from the port
priority and the interface number.

Port ID

Indicates the current STP state of the interface. If enabled, the port state
determines what forwarding action is taken on traffic. Possible port states
are as follows:
Disabled: STP is currently disabled on the interface. The interface

forwards traffic while learning MAC addresses.

Blocking: The interface is currently blocked and cannot be used to

forward traffic or learn MAC addresses.

Listening: The interface is currently in the listening mode. The interface

cannot forward traffic nor can it learn MAC addresses.

Learning. The interface is currently in the learning mode. The interface

cannot forward traffic. However, it can learn new MAC addresses.

Forwarding: The interface is currently in the forwarding mode. The

interface can forward traffic and learn new MAC addresses.

Manual forwarding: The interface is currently in the manual forwarding

mode. The interface can forward traffic and learn new MAC addresses

Port Forwarding State

Each MST bridge port that is enabled is assigned a port role for each
spanning tree. The port role is one of the following: Root, Designated,
Alternate, Backup, Master, or Disabled.

Port Role

The root bridge for the CST, which is created from the bridge priority and
the base MAC address of the bridge.

Designated Root

The path cost offered to the LAN by the designated port.

Designated Cost

The bridge identifier of the bridge with the designated port. This identifier
is created from the bridge priority and the base MAC address of the
bridge.

Designated Bridge
